Single Sided Corrugated Cardboard Production Line
Process configuration of 120 meter single-sided corrugated cardboard production line: 1. Maximum production width: 1400-2200mm Design speed: 150m/min Economic speed: 100-120m/min Note: The paper used for production line speed testing should meet the following requirements: (The surface temperature of the equipment should not be lower than 172 ℃ or above) The grade of the base paper shall not be lower than Grade B. The moisture content of the base paper is approximately 11% ± 2% * Face paper: 100-250g/m2 * Core paper: 100-180g/m2 2. Corrugated combination: A, C, B, E (or customer's choice) 3. Steam volume is about 500Kg/Hr, maximum pressure: 1.2Mpa, commonly used pressure: 0.8-1.1Mpa 4. Power supply: 380V 50Hz three-phase four wire system 5. Total installed power of the equipment: about 90KW Actual power consumption: about 30KW 6. Equipment footprint: approximately 30m x 11m x 5m (specific length subject to foundation drawing) 7. Equipment paper output direction: Determine wheth…
