Smart Single Phase Rail Wi-Fi Energy Meter D52-2068

Smart Single Phase Rail Wi-Fi Energy Meter D52-2068

The Smart Single Phase Rail Wi-Fi Energy Meter D52-2068 from Zhejiang Chenhai Electric combines accurate six‑parameter measurement with Tuya Wi‑Fi connectivity. It displays current (AC 0-100.0A), voltage (AC 40.0-300.0V or 250.0-450.0V), frequency (45.0-65.0Hz), power factor (0.00-1.00), active power (0-30000W), and energy (0-99999kWh on the device, unlimited on the mobile app). The LCD color screen shows all values simultaneously. Sampling rate is 2 times per second. Mounting is on standard C45 35mm DIN rail with dimensions 54x48x80mm. Both built‑in and external current transformer options are available. The integrated Tuya Wi‑Fi allows users to bind the device via WeChat mini program and view real‑time measurement data on their phones, enabling remote monitoring from anywhere. This smart meter works seamlessly with Power Meters & Rail-mounted Energy Meters for comprehensive panel integration. For complete electrical safety, pair it with Circuit Breakers and Microcomputer Protecti…
