BLM10D1822-60ABGZ RF MOSFET LDMOS
BLM10D1822-60ABG LDMOS 2-stage integrated Doherty MMIC BLM10D1822-60ABGZ is a 10th‑generation LDMOS two‑stage fully integrated Doherty MMIC by Ampleon, operating at 1800~2200 MHz. Optimized for 4G/5G macro base stations and mMIMO final/driver stages, the “Z” suffix indicates RoHS‑compliant lead‑free (identical performance to BLM10D1822-60ABG). It integrates an input splitter, two‑stage Doherty amplifier, output combiner and pre‑matching network on a single chip, featuring high power, high efficiency and high integration, simplifying peripheral circuits for compact high‑power base station PAs. Key Specifications Manufacturer: Ampleon Part Number: BLM10D1822-60ABGZ Frequency Range: 1800~2200 MHz Typical Average Output Power: 60 W Saturated Output Power: 75 W typical Power Gain: 30 dB typical Drain Efficiency: 48% typical (at 60 W average power) Supply Voltage: 28 V Package: PQFN20 (gull‑wing, surface mount) Technology: 10th‑generation silicon LDMOS (GEN10 LDMOS) Status: In prod…
