41T heavy-duty reinforced bucket

Website:

41T heavy-duty reinforced bucket

Overview The reinforced bucket for 40-ton excavators has a bucket volume of 1.8 cubic meters and a widened bucket body. It is made of three layers of composite wear-resistant steel and features a 55mm ultra-thick blade plate. The overall structure is reinforced, making it suitable for large-scale earth and rock excavation, hard soil crushing, and auxiliary mining operations involving high-impact and continuous work.   Specification     Model Bucket Type Machine Tonnage Bucket Capacity (m³) Bucket Width (mm) Main Material Cutting Edge Thickness (mm) Optional Castings  Applicable Working Conditions 41T-1.8m³ Reinforced bucket 41 1.8 1560 WH60C Q355B NM400 55 Retaining Pin J450-R   Side Tooth S30119587H Pin J450-P   Bucket Tooth 1U3452RC-N Tooth Adapter 6I6464V(55) General earthwork, medium-hard soil, and mixed soil containing small amounts of crushed stone. Core product performance   1. Long service life Three-layer composite steel + integral reinforcement structur…
