Improved type Ⅱ rail fastening system Russia standard

Improved type Ⅱ rail fastening system Russia standard

Improved type Ⅱ rail  fastening was improved from chemical anchor bolt to plastic insert anchor type, it is mostly used in China or Russia standard rail like 60kg/m or p43, 50kg or R50, with ballast track,concrete sleeper with shoulder block. The main advantage is easy to replace and maintenance, cost economic.railroad, ballast or ballast less track. Main components: * Tension clamp  China type Ⅱ  --2pcs *Steel guide plates--2pcs * Insulator--2pcs * Rail pad--1pc *Plastic insert dowels--2pc *Double lead anchor bolt--2pc *Hex Nuts--2pc *Flat washers--2pc Components description: W type Rail elastic clip/ SKL clip Raw material: 60Si2CrA, 38Si7,60SI2MN Type:China type Ⅱ Surface: plain ( oil), black paint, color paint, etc Rail pad Raw material: Rubber Surface: plain Insulator Raw material:PA66+30%GF Surface: plain Steel guide plates Raw material:PA66+30%GF Su…
